RAVENOL Calibration Fluid 2.5 is a low viscosity test fluid for the calibration of diesel injection pumps with a very close viscosity tolerance. It is noted for its excellent wear-, corrosion-protection and low foaming tendency. The product is also suitable for use as corrosion protection oil for the internal preservation or conservation of fuel systems from MTU.
Application Note
RAVENOL Calibration Fluid 2.5 is used as a test fluid for the calibration of diesel injection pumps from Bosch (VS 15665-OL), MTU, MAN and Volkswagen. The product is also suitable for use as corrosion preventive oil for the internal preservation or conservation of fuel systems from MTU.
Characteristics
- Excellent wear protection
- Excellent corrosion protection
- Low tendency to foam
Technical Product Data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Density at 20 °C | kg/m³ | 821 | EN ISO 12185 |
| Colour | farblos | VISUELL | |
| Viscosity at 40 °C | mm²/s | 2,52 | DIN EN ISO 3104 |
| Viscosity at 20 °C | mm²/s | 3,85 | DIN EN ISO 3104 |
| Flashpoint | °C | 105 | DIN 51757 |
| Cloudpoint | °C | -28 | ASTM D2500 |
| Steel corrosion | 0-A | DIN ISO 7120 | |
| Copper strip corrosion | 1 | DIN EN ISO 2160 | |
| Corrosion test (humidity chamber) | 6x0 | ASTM D1748 | |
| Initial Boiling Point | °C | 232 | DIN 51751 |
| Final Boiling Point | °C | 265 | DIN 51751 |
All indicated data are approximate values and are subject to the commercial fluctuations.
