RAVENOL STF Synchromesh Transmission Fluid is a full synthetic transmission oil based on high-quality synthetic base oils with a special additive treatment and inhibition ensuring trouble-free transmission function. This exceeds the needs of today's application requirements.
RAVENOL STF Synchromesh Transmission Fluid is a specially developed, modern transmission oil for manual transmissions and transfer cases by GM and Chrysler. Guarantees maximum wear protection under any operating conditions.
Application Note
RAVENOL STF Synchromesh Transmission Fluid is especially suited for the following GM and Chrysler manual transmissions and transfer gearboxes:
New Venture Gear NV T350, NV 1500, NV 2550, NV 3500, NV 3550, NV 5600
Chrysler NSG370 for Jeep Liberty 2005-2008, Jeep Wrangler 2005- , Chrysler Crossfire
Tremec T4, T5, T18, T56, T176, TKO500, TKO600, TR 3450 and TR 3550.
Not for use in hypoid gear rear axles or limited slip.
Characteristics
- A high pressure stable lubricating film even at high oil temperatures and under high stress.
- Outstanding shearing stability and excellent thermal stability.
- Excellent viscosity-temperature properties.
- High oxidation stability.
- Excellent wear protection, outstanding EP properties.
- Low foaming properties even at high speeds.
- Good shifting behaviour even in low temperatures, extremely low pour point.
- Extended life.
Technical Product Data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Density at 20 °C | kg/m³ | 842,0 | EN ISO 12185 |
| Colour | gelbbraun | VISUELL | |
| Viscosity at 100 °C | mm²/s | 7,4 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 36,5 | DIN 51562-1 |
| Viscosity Index VI | 175 | DIN ISO 2909 | |
| Brookfield Viscosity at -40 °C | mPa*s | 8.900 | ASTM D2983 |
| Pourpoint | °C | -51 | DIN ISO 3016 |
| Flashpoint | °C | 210 | DIN EN ISO 2592 |
| Copper Strip Test at 121 °C | 1b | ASTM D130 |
All indicated data are approximate values and are subject to the commercial fluctuations.
