RAVENOL SGO SAE 80W-140 GL-5 is a synthetic transmission oil for high loaded hypoid gearboxes based on high quality synthetic base oils and additives that are a balanced combination of active ingredients. Special high-pressure (EP) agents and other additives offer excellent wear protection for RAVENOL SGO SAE 80W-140 GL-5 even under severe operating conditions.
Application Note
RAVENOL SGO SAE 80W-140 GL-5 is designed for use in highly loaded, hypoid gears for hypoid gearbox, as well as for axle, transfer case, transmission gear, auxiliary gearboxes in vehicles and machinery and for use as an extreme pressure gear oil where this grade of lubricant is specified by the manufacturer.
Characteristics
- A pressure-resistant lubricating film, excellent high-pressure (EP) properties
- High viscosity index
- Excellent oxidation stability
- An exceptional viscosity-temperature behavior
- A low pour point
- Excellent protection against rust and corrosion
- Wear-resistant effect
- Good air separation capacity, no foam formation
Technical Product Data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Density at 20 °C | kg/m³ | 850,0 | EN ISO 12185 |
| Colour | hellgelb | VISUELL | |
| Viscosity at 100 °C | mm²/s | 27,5 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 205,1 | DIN 51562-1 |
| Viscosity Index VI | 171 | DIN ISO 2909 | |
| Brookfield Viscosity at -12 °C | mPa*s | 32.000 | ASTM D2983 |
| Pourpoint | °C | -33 | DIN ISO 3016 |
| Flashpoint | °C | 202 | DIN EN ISO 2592 |
| Copper Strip Test at 121 °C | 1a | ASTM D130 |
All indicated data are approximate values and are subject to the commercial fluctuations.
