RAVENOL DCT/DSG Getriebe Fluid is a synthetic DCT (Dual Clutch Transmission) Fluid, designed on the basis of high quality hydrocrack oils with components of PAO and a special additive inhibition, which ensure a perfect function of the dual clutch transmission.
RAVENOL DCT/DSG Getriebe Fluid guarantees good lubricating properties even at extremely temperatures in summer and low winter temperatures.
RAVENOL DCT/DSG Getriebe Fluid allows virtually slip-free operation and thus minimal torque losses. Ensures low wear and long life of the transmission. Fuel economy.
Application Note
RAVENOL DCT/DSG Getriebe Fluid has been developed especially for Dual Clutch Gear of several manufacturers like VW/Audi, Ford, Volvo, Chrysler, Dodge, Mitsubishi and others.
RAVENOL DCT/DSG Getriebe Fluid is also recommended for use in Dual Clutch Gear DQ-250 (02E) and DQ-500 (0BT) acc. to VW Part-No. G 052 182 of VW, Audi, Seat and Skoda.
RAVENOL DCT/DSG Getriebe Fluid is recommended by Fa. Drexler for all DCG-transmissions with MibaCarbon plates.
Characteristics
- Good lubricating properties also at low temperatures in winter
- Stable lubricant film even under extreme loads in summer
- Low wear
- Excellent viscosity-temperature behaviour
- Very low pour point
- Low foaming even under heavy demands
- Extensive protection against wear, corrosion and foaming
- Neutral behavior towards sealing materials
Technical Product Data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Density at 20 °C | kg/m³ | 840,0 | EN ISO 12185 |
| Colour | gelbbraun | VISUELL | |
| Viscosity at 100 °C | mm²/s | 7,4 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 35,1 | DIN 51562-1 |
| Viscosity Index VI | 184 | DIN ISO 2909 | |
| Pourpoint | °C | -51 | DIN ISO 3016 |
| Flashpoint | °C | 204 | DIN EN ISO 2592 |
All indicated data are approximate values and are subject to the commercial fluctuations.
RAVENOL special transmission fluids are special developments for special gears and cannot be selected on the basis of technical parameters (viscosity, etc.). Therefore the decision was made not to give technical data. Please note: RAVENOL special transmission fluid is exclusively to apply under the original number, as indicated in the product information. If you are unsure about the right transmission fluid, ask your workshop or dealership for advice on the transmission type and OEM original number or ask our experts, making sure to state the VIN code (vehicle identification number) of your vehicle. Misapplication of RAVENOL special transmission fluid can lead to malfunction of the transmission shifting problems, increased fuel consumption, unwanted slip behavior, etc. and cause the failure of the transmission. Ravensberger Schmierstoffvertrieb GmbH is not liable for transmission failures in case of wrong selection of RAVENOL special transmission fluid.
