RAVENOL PDK Fluid is a full synthetic automatic transmission oil ATF with low viscosity and with special additives and inhibition to ensure the proper operation of the automatic transmission.
RAVENOL PDK Fluid was specially developed for Porsche Doppelkupplungsgetriebe (Dual clutch transmission). In addition, it meets the requirements of the S6-35 / S6-45 manual transmissions used by BMW and Mercedes Benz.
RAVENOL PDK Fluid guarantees maximum wear protection in all operating conditions.
Application Note
RAVENOL PDK Fluid has been developed especially for use in Dual Clutch Gears from Porsche.
| Transmission | Torque | Application |
|---|---|---|
| 7DT-45HL | 500 Nm | Porsche 911 |
| 7DT-45HLA | 500 Nm | Porsche 911 4-Wheel-Drive |
| 7DT-45FL | 500 Nm | Porsche Boxster and Cayman |
| 7DT-70HLA | 780 Nm | Porsche 911 Turbo |
| 7DT-75 | 500/780 Nm | Porsche Panamera |
| 7DT-75A | 500/780 Nm | Porsche Panamera 4-Wheel-Drive |
Characteristics
- Very good lubrication even at low temperatures in winter
- High, stable viscosity index
- Very good oxidation stability
- Extensive protection against wear, corrosion and foaming
- Excellent friction coefficient
- High thermal and oxidative stability
- Excellent cooling performance
Technical Product Data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Density at 20 °C | kg/m³ | 844,0 | EN ISO 12185 |
| Colour | gelb | VISUELL | |
| Pourpoint | °C | -63 | DIN ISO 3016 |
All indicated data are approximate values and are subject to the commercial fluctuations.
RAVENOL special transmission fluids are special developments for special gears and cannot be selected on the basis of technical parameters (viscosity, etc.). Therefore the decision was made not to give technical data. Please note: RAVENOL special transmission fluid is exclusively to apply under the original number, as indicated in the product information. If you are unsure about the right transmission fluid, ask your workshop or dealership for advice on the transmission type and OEM original number or ask our experts, making sure to state the VIN code (vehicle identification number) of your vehicle. Misapplication of RAVENOL special transmission fluid can lead to malfunction of the transmission shifting problems, increased fuel consumption, unwanted slip behavior, etc. and cause the failure of the transmission. Ravensberger Schmierstoffvertrieb GmbH is not liable for transmission failures in case of wrong selection of RAVENOL special transmission fluid.
